Flatbed CAD Cutting Table machine

?

Brief Introduction:

1.????? Two interchangeable tools, whole sets head design, convenient to change cutting tools.

2.????? Four spindles high speed controller, modularizing installing, convenient for maintenance.

3.????? Cutting depth could be adjusted as customers need.

4.????? Easy to set parameter, different materials could be processed just after the cutting thickness and cutting speed are set well.

5.????? Application: make samples and small production in the industries such as packaging, ads, sign, display etc.

?

?

?

Description:

?

GSB70 series flatbed digital cutter is the new developed carton box sample making system, the capability improves a lot comparing with the former, not only the processing speed, processing accuracy, convenient operation, but also the impressive surface. GSB70 series sample making machine make cutting, creasing, drawing available undertaking machine’s stable, high speed, high accuracy. It could meet sample making or small production require of packing company, corrugated box manufacturer, color box manufacturer, color printing manufacturer, die cutting manufacturer. It could cut corrugated board, chipboard, foam board, plastic board, thin wood board, leather, cloth, honeycomb board, KT board etc. We are great reputed by customers from packaging, advertisement, printing, die cutting, electron, gasket, sign industries. The GSB70 win great support from Shanghai Technology Small and Medium Enterprises Technical Innovation Fund. With a full complement of cutting and creasing tools, it is an extremely versatile cutting system. With a large range of sizes(from 1300*1000mm to 2500*1600mm), it includes advanced tooling(oscillating knife, drag knife,creasing tool and pen), laser registration device, powerful vacuum hold-down(5.5KW), quiet operation and a built-in safety beam. The system includes a PC front end with Windows graphical user interface. This front end allows users to use the system as an independent off-line production system or as a CAD peripheral, compatible with almost all major CAD systems on the market today. State of the art electronics include digital servo controls for high-precision results.? Rugged construction insures reliability and longevity.

?

?Characteristics:

?

1. Cutting function of oscillation tool

?

It can cut many different materials (such as corrugated paper, cardboard, offset??paper, grey board, rubber, honeycomb board, PP,PE,PVC, gasket, leather ,carpet and mat )

?

2. Folding function

?

It can fold corrugated paper, card paper and offset board into perfect folding line.

?

3. Function of dotted line

?

It is used to fold them after half cutting corrugated paper and grey card paper, and to cut dotted line.

?

4. Location

?

??? Location with laser.

?

5. Drawing function

?

It can draw various high precision drawing cutting materials: corrugated board,??foam, PVC, styrene, Coroplast, Celtec, magnetic film, adhesive vinyl, leather, rubber, fabrics, high intensity reflective films, paper, cardboard, polystyrene, magnetic films, vinyl?etc.

?

?

?

?Specifications

?

Model	GSB702516	GSB701713	GSB701310
Effective cutting area(mm)	2500*1600	1700*1300	1300*1000
Configuration	Oscillating knife,drag knife,pen,creasing tool
Max speed	1350mm/s
Max cutting thickness	30mm
Smallest cutting diameter	6mm
Precision	≤0.1mm
Voltage	220V±10% 50HZ
Input cushion	32MB
Vacuum	5.5KW
Control system	Servo
Data format	HPGL, DXF, PDF
Data port	Parallel port, Serial port, USB port
Data transmission speed	10MB/S
Option	?? Video registration system,V cut knife, foam cutting knife, convey belt
Occupy dimension(L*W*H) (mm)	3400*2460*1180	2600*2160*1180	2200*1860*1180
Note: Other sizes can be customized

?

?

?

?

?

?

?

F.?Packaging?&?Shipping:?

GSP0906:?

Plywood?carton?box?packing:?Size?1480mm*1200mm*500mm?CBM:?0.88mm?Weight:?200kgs

GSP1209:

Plywood?carton?box?packing:?Size?1780mm*1500mm*500mm?CBM:?1.33mm?Weight:?260kgs

GSP1509:

Plywood?carton?box?packing:?Size?2080mm*1500mm*500mm?CBM:?1.33mm?Weight:?280kgs

?

G.?Our?Services:

1.?QC?System:100%?inspection?before?shipment.

2.?Drawing?format:?CAD?/?PDF/?DWG/?IGS/?STEP

3.?Packaging:?Standard?package?/?Pallet?or?container?/?As?per?customized?specifications

4.?Payment?Terms:?30?-50%T/T?in?advance,

???70-50%?balance?before?delivery;?L/C,?PayPal?or?Western?Union?is?acceptable.

H.?Shipment?Terms:

DHL,?UPS,?EMS,?TNT,?Fedex,?sea?transportation?are?available

I.?Trade?terms:

EXW,?FOB,?CIF?preferred

The?pictures?for?your?reference

?

?
