Horizontal Heavy Duty Manual Engine Lathe Machine CW61100
Horizontal Heavy Duty Manual Engine Lathe Machine CW61100
Horizontal Heavy Duty Manual Engine Lathe Machine CW61100
Horizontal Heavy Duty Manual Engine Lathe Machine CW61100
Horizontal Heavy Duty Manual Engine Lathe Machine CW61100
Horizontal Heavy Duty Manual Engine Lathe Machine CW61100
Horizontal Heavy Duty Manual Engine Lathe Machine CW61100

Video

1 / 7

Horizontal Heavy Duty Manual Engine Lathe Machine CW61100

  • $32500.00

    ≥1 set

  • $32000.00

    ≥2 set

Options:

  • 1000
Get Latest Price

Basic Info

Model No.
Brand Name
Max. Length Of Workpiece (mm) 1500
Range Of Spindle Speed(r.p.m) 6 - 720 R.P.M
Machining Capacity Heavy Duty
Width Of Bed (mm) 600
Type Horizontal
Spindle Motor Power(kW) 11
Place Of Origin Shandong, China
Brand Name SDCNC
Model Number Cw61100
Voltage Customer choice
Dimension(L*W*H) 2500*1400* 1450
Weight (KG) 5300 KG
Warranty 1 Year
Key Selling Points Competitive Price
Marketing Type New Product 2024
Machinery Test Report Provided
Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year
Product name Manual Lathe Machine CW61100
Key Word Torno Lathe Machine
Keyword 2 Lathe Manual
Key Word3 Horizontal Lathe
Model CW61100
Color Customrized
Condition New
Spindle Bore(mm) 104
Applicable Industries Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Retail, Construction works
Showroom Location None
Core components Bearing
Max. Turned Length (mm) 1320
Year 2024
Show More

Product description

Products Description
Product Paramenters
Type
CW61100B
Capacity
Max. swing over bed
1000 mm
Max. swing over cross slide
610 mm
Distance between centers
1500/3000 mm
Guideway width
755 mm
Max. Load capacity
6T
Spindle
Spindle bore
130 mm
Spindle bore taper
Metric φ140/MT6
Spindle nose type
A2-15
Spindle speed steps
FWD. 21 steps
Spindle speed range
3.15-315 rpm
Chuck
Φ1000mm 4-jaw manual
Turret
Turret/Tool post
Manual turret 4 position
Tool shank size
45x45mm
Feed
X axis travel
520 mm
Z axis travel
1350/2850 mm
X axis feed grade/range
56/0.05-6 mm/r
Z axis feed grade/range
56/0.1-12 mm/r
X axis rapid traverse
1870 mm/min
Z axis rapid traverse
3740 mm/min
Metric thread grade/range
44/1-120 mm
Inch thread grade/range
31/28-3/8 TPI
Module thread grade/range
45/0.5-60 mm
DP thread grade/range
30/56-1 D.P.
Tailstock
Tailstock quill diameter
Φ140 mm
Tailstock quill taper
MT6
Tailstock quill travel
300 mm
Motor
Main spindle motor
22 kw
Rapid traverse motor
1.5 kw
Coolant pump motor
0.125 kw
Dimension
Width X Height
2000X1950 mm
Length
4600 /6100mm
Net weight
10.6 /11.7 T
Recommend Products
COMPANY PROFILE
Shandong Shansu CNC Machine Tool Co., Ltd. is located in the traffic developed, economic prosperity of China's Shandong Tengzhou City, is a professional engaged in CNC machine tool development and machinery manufacturing manufacturers. The company with strong technical force, high quality and good reputation to win the trust of foreign trade users. Mainly produces CNC machine tool equipment (CNC lathe, machining center horizontal machining center, vertical machining center, CNC vertical lathe, CNC pipe thread lathe, CNC milling machine, CNC drilling machine, CNC slotting machine, CNC sawing machine and other CNC products) ordinary lathe, milling machine series, shaper machine, metal sawing machine, slotting machine series, radial drilling machine, vertical drill Bed and other machine tools.
OUR CERTIFICATE
Deliver goods

Q: WHO ARE WE? A: WE ARE A PROFESSIONAL MACHINE TOOL MANUFACTURER. WE NOT ONLY SELL OUR MACHINES, BUT ALSO PROVIDE TECHNICAL SUPPORT. Q: HOW DO WE ENSURE QUALITY? A: EVERY NEW MACHINE HAS T0 G0 THROUGH STRICT TESTING AND CONF IRMATION FIRST. INSPECTION OF EACH PART INSPECTION AND ADJUSTMENT 0F EMPTY LINE AFTER ASSEMBLY Q: WHAT CAN YOU BUY FROM US? A: LATHES, CNC LATHES, CNC PIPE THREAD LATHES, CNC VERTICAL LATHE, CNC MACHINE T00LS, ORDINARY PIPE THREAD LATHES, MACHINING CENTERS, H0BBING MACHINES, DRILL ING MACHINES, MILLING MACHINES,GRINDING MACHINES,SAWING MACHINE, ETC.. . Q:WHY SHOULD YOU BUY FROM US INSTEAD 0F OTHER SUPPLIERS? MANY YEARS 0F MACHINE T00L PRODUCTION IN RESEARCH AND DEVELOPMENT EXPERIENCE,G00D EXPER IENCE,G00D PERFORMANCE, GOOD QUALITY,LET USERS BUY DON'T WORRY, USE IT AT EASE。
