Hot Sale C6140 Horizontal Lathe for Metal Working
Hot Sale C6140 Horizontal Lathe for Metal Working
Hot Sale C6140 Horizontal Lathe for Metal Working
Hot Sale C6140 Horizontal Lathe for Metal Working
Hot Sale C6140 Horizontal Lathe for Metal Working
Hot Sale C6140 Horizontal Lathe for Metal Working
Hot Sale C6140 Horizontal Lathe for Metal Working

Video

1 / 7

Hot Sale C6140 Horizontal Lathe for Metal Working

  • $4800.00

    ≥1 set

  • $4550.00

    ≥2 set

Options:

  • 320
Get Latest Price

Basic Info

Model No.
Brand Name
Max. Length Of Workpiece (mm) 750
Range Of Spindle Speed(r.p.m) 40 - 1400 R.P.M
Machining Capacity Light Duty
Width Of Bed (mm) 360
Type Horizontal
Spindle Motor Power(kW) 4
Place Of Origin Shandong, China
Brand Name SDCNC
Model Number C6140
Voltage 220V/380V
Dimension(L*W*H) 2200 * 1140 *1750
Weight (KG) 1100 KG
Warranty 1 Year
Key Selling Points Competitive Price
Marketing Type New Product 2024
Machinery Test Report Provided
Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year
Product name Manual Lathe Machine C6140
Key Word Torno Lathe Machine
Keyword 2 Lathe Manual
Key Word3 Horizontal Lathe
Model C6140
Color Customrized
Condition New
Spindle Bore(mm) 52
Applicable Industries Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Retail, Construction works
Showroom Location None
Core components Bearing
Max. Turned Length (mm) 1500
Year 2024
Show More

Product description

Products Description
Product Paramenters
SPECIFICATIONS
Units
C6140
Swing over bed
mm
400
Swing over cross slide
mm
230
Swing over gap
mm
-
Distance between centers
mm
750/1000/1500/2000/3000
Spindle bore
mm
52(Optional:80)
Spindle bore taper
-
MT6(Optional:Metric 1:20)
Spindle speed steps
-
9
Spindle speed range
rpm
40-1400
Cross slide travel
mm
200
Top tool post travel
mm
95
Longitudinal feeds range
mm/r
0.0832-4.6569
Cross feeds range
mm/r
0.048-2.688
Kinds of metric threads
kinds
19
Range of metric threads
mm
0.25-14
Kinds of inch threads
kinds
28
Range of inch threads
T.P.I.
2-40
Kinds of threads module
kinds
17
Range of threads module
MP
0.25-3.5
Tailstock quill diameter
mm
65
Tailstock quill taper
-
MT4
Tailstock quill travel
mm
130
Main motor power
kw
4
Coolant pump motor
kw
0.09
Weight for 750
kg
1220
Weight for 1000
kg
1320
Weight for 1500
kg
1520
Weight for 2000
kg
1720
Weight for 3000
kg
1920
Dimension for 750
mm
2200x1140x1750
Dimension for 1000
mm
2400x1140x1750
Dimension for 1500
mm
2900x1140x1750
Dimension for 2000
mm
3400x1140x1750
Dimension for 3000
mm
4400x1140x1750
Recommend Products
COMPANY PROFILE
Shandong Shansu CNC Machine Tool Co., Ltd. is located in the traffic developed, economic prosperity of China's Shandong Tengzhou City, is a professional engaged in CNC machine tool development and machinery manufacturing manufacturers. The company with strong technical force, high quality and good reputation to win the trust of foreign trade users. Mainly produces CNC machine tool equipment (CNC lathe, machining center horizontal machining center, vertical machining center, CNC vertical lathe, CNC pipe thread lathe, CNC milling machine, CNC drilling machine, CNC slotting machine, CNC sawing machine and other CNC products) ordinary lathe, milling machine series, shaper machine, metal sawing machine, slotting machine series, radial drilling machine, vertical drill Bed and other machine tools.
OUR CERTIFICATE
Deliver goods

Q: WHO ARE WE? A: WE ARE A PROFESSIONAL MACHINE TOOL MANUFACTURER. WE NOT ONLY SELL OUR MACHINES, BUT ALSO PROVIDE TECHNICAL SUPPORT. Q: HOW DO WE ENSURE QUALITY? A: EVERY NEW MACHINE HAS T0 G0 THROUGH STRICT TESTING AND CONF IRMATION FIRST. INSPECTION OF EACH PART INSPECTION AND ADJUSTMENT 0F EMPTY LINE AFTER ASSEMBLY Q: WHAT CAN YOU BUY FROM US? A: LATHES, CNC LATHES, CNC PIPE THREAD LATHES, CNC VERTICAL LATHE, CNC MACHINE T00LS, ORDINARY PIPE THREAD LATHES, MACHINING CENTERS, H0BBING MACHINES, DRILL ING MACHINES, MILLING MACHINES,GRINDING MACHINES,SAWING MACHINE, ETC.. . Q:WHY SHOULD YOU BUY FROM US INSTEAD 0F OTHER SUPPLIERS? MANY YEARS 0F MACHINE T00L PRODUCTION IN RESEARCH AND DEVELOPMENT EXPERIENCE,G00D EXPER IENCE,G00D PERFORMANCE, GOOD QUALITY,LET USERS BUY DON'T WORRY, USE IT AT EASE。
