Video
1 / 7
$12000.00
≥1 set
$11500.00
≥2 set
Options:
Basic Info
| Max. Length Of Workpiece (mm) | 1000 |
|---|---|
| Range Of Spindle Speed(r.p.m) | 6 - 800 R.P.M |
| Machining Capacity | Light Duty |
| Width Of Bed (mm) | 550 |
| Type | Horizontal |
Product description






Specification | Unit | CW6163E/CW6263E | CW6180E/CW6280E | ||||
Swing over bed | mm | 630 | 800 | ||||
Swing over gap | mm | - | 800 | - | 1000 | ||
Swing over cross slide | mm | 350 | 520 | ||||
Distance between centers | mm | 1500/2000/3000/ 4000/5000/6000 | 1500/2000/3000/ 4000/5000/6000 | ||||
Guideway width | mm | 550 | 550 | ||||
Max. load capacity | T | 3 | 3 | ||||
Spindle bore | mm | 104 | 104 | ||||
Spindle bore taper | - | Metric φ120/MT5 | Metric φ120/MT5 | ||||
Spindle nose type | - | C11 | C11 | ||||
Spindle speed steps | - | FWD. 18 steps | FWD. 18 steps | ||||
Spindle speed range | rpm | 7.5-1000 | 6-800 | ||||
Chuck | mm | φ315 3-jaw manual | φ315 3-jaw manual | ||||
Turret/tool post | - | Manual turret 4 position | Manual turret 4 position | ||||
Tool shank size | mm | 30 x 30 | 30 x 30 | ||||
X axis travel | mm | 320 | 420 | ||||
Z axis travel | mm | 1350/1850/2850/ 3850/4850/5850 | 1350/1850/2850/ 3850/4850/5850 | ||||
X axis feed grade/range | mm/r | 64/0.05-12.15 | 64/0.05-12.15 | ||||
Z axis feed grade/range | mm/r | 64/0.1-24.3 | 64/0.1-24.3 | ||||
X axis rapid traverse | mm/min | 2300 | 2300 | ||||
Z axis rapid traverse | mm/min | 4000 | 4000 | ||||
Metric thread grade/range | mm | 50/1-240 | 50/1-240 | ||||
Inch thread grade/range | T.P.I | 26/14-1 | 26/14-1 | ||||
Module thread grade/range | mm | 53/0.5-120 | 53/0.5-120 | ||||
DP thread grade/range | D.P. | 24/28-1 | 24/28-1 | ||||
Tailstock quill diameter | mm | φ100 | φ100 | ||||
Tailstock quill taper | - | MT5 | MT5 | ||||
Tailstock quill travel | mm | 250 | 250 | ||||
Main spindle motor | kW | 11 | 11 | ||||
Rapid traverse motor | kW | 1.1 | 1.1 | ||||
Coolant pump motor | kW | 0.125 | 0.125 | ||||
Width x Height | mm | 1400 x 1450 | 1500 x 1450 | ||||
