ASCO Type MP-C-146 Solenoid Coil 24VDC 110VAC 220VAC
Basic Info
| Model No. | BB11436248 |
|---|---|
| Brand Name | BRANDO |
| Product Name | Solenoid Valve Coil |
| Connector | DIN43650A |
| Ordering Code | MP-C-146 |
| Voltage | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Hole Size | 11.0mm |
Product description
ASCO Type MP-C-146 Solenoid Coil 24VDC 110VAC 220VAC
This MP-C-146 solenoid coil is popularly used in ASCO solenoid valves. Solenoid Coil Reference Number: 238513-006, 238513-017, 238213-006, 238213-016, 238213-033, 238213-059, 238513-106, 238513-117, 238213-106, 238213-116, 238213-133, 238213-157. Solenoid Coil Standard Voltage: 24VDC, 48VDC, 24VAC, 48VAC, 110VAC, 220VAC. Solenoid Coil Standard Power: 21VA, 18W. Other voltage and power can be customized. The solenoid coil is integral in the operation of a solenoid valve. It is what converts the electric current into a magnetic field which in turn allows the operation of the solenoid valve.
Dimension & Data of Solenoid Valve Coil MP-C-146:
|
BRANDO Model
|
BB11436248
|
|
Voltage
|
24VDC, 48VDC,
24VAC, 48VAC, 110VAC, 220VAC |
|
Power
|
21VA, 18W
|
|
Other voltage and power can be customized
|
|
|
Insulation Class
|
H, F
|
|
Connector
|
DIN43650A
|
Reference Number of MP-C-146 Solenoid Coil:
|
Model No
|
24V DC
|
48V DC
|
24V AC
|
48V AC
|
115V AC
|
230V AC
|
|
M6-HT
|
238513-006
|
238513-017
|
-
|
-
|
-
|
-
|
|
M6-FT
|
-
|
-
|
238213-006
|
238213-016
|
238213-033
|
238213-059
|
|
M6-HB
|
238513-106
|
238513-117
|
-
|
-
|
-
|
-
|
|
M6-FB
|
-
|
-
|
238213-106
|
238213-116
|
238213-133
|
238213-157
|
|
MXX-HT
|
238913-006
|
238913-017
|
-
|
-
|
-
|
-
|
|
MXX-FT
|
238713-006
|
238713-017
|
238613-006
|
238613-016
|
238613-033
|
238613-059
|
|
MXX-HB
|
238913-106
|
238913-117
|
-
|
-
|
-
|
-
|
|
MXX-FB
|
-
|
-
|
238613-106
|
238613-116
|
238613-133
|
238613-159
|
BRANDO Solenoid Valve Coils Production:
More Solenoid Valves for you to choose:
 |
 |
 |
| Brass Solenoid Valve | Stainless Steel Solenoid Valve | Plastic Solenoid Valve |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
