Encoder for control encoder
Options:
- Dimension ：［mm］ Ф66*89
- Shaft size /aperture ：φ［mm］ 15
- Max. rotate speed： ［r/min］ 6000
- Max. rotate speed ：［r/min］ 6000
- resolution ：［P/r］ 1024
- Supply voltage： DC［V］ 5
Basic Info
| Model No. | B-ZXF-FA-L30-200BM-C05L |
|---|---|
| Brand Name | Yuheng |
| Application | CNC machine tools、automation、metallurgical industry Feature high protection level，economical Model ［unit］ B-ZXF-FA-L30-200BM-C05L Mechanical parameter Dimension ［mm］ Ф66*89 Shaft type Solid shaft Shaft size /aperture φ［mm］ 15 Max. rot |
| Feature | high protection level，economical |
| Model | ［unit］ B-ZXF-FA-L30-200BM-C05L? |
| Shaft type | Solid shaft |
| Operating temperature | ［℃］ -20～+85 |
Product description
In the article from self encoder to Variational self encoder, we discuss the model of taking data as input and finding some potential state representation of data (incomplete, sparse, noise reduction, compression).
| Application | CNC machine tools、automation、metallurgical industry | |
| Feature | high protection level，economical | |
| Model | ［unit］ | B-ZXF-FA-L30-200BM-C05L |
| Mechanical parameter | ||
| Dimension | ［mm］ | Ф66*89 |
|
Shaft type |
Solid shaft |
|
|
Shaft size /aperture |
φ［mm］ | 15 |
|
Max. rotate speed |
［r/min］ | 6000 |
|
Max. shaft load Axial / Radial |
［N］ | 50/50 |
|
Operating temperature |
［℃］ | -20～+85 |
|
Protection level |
IP65 | |
|
Connection type |
Coupling | |
|
resolution |
［P/r］ | 1024 |
|
Electrical parameter |
||
|
Output pattern |
Line driver | |
|
Supply voltage |
DC［V］ | 5 |
| Response frequency / Response rate | ［KHz］ | 300 |
|
Optional |
Encoder for control encoder
Options:
- Dimension ：［mm］ Ф66*89
- Shaft size /aperture ：φ［mm］ 15
- Max. rotate speed： ［r/min］ 6000
- Max. rotate speed ：［r/min］ 6000
- resolution ：［P/r］ 1024
- Supply voltage： DC［V］ 5
