Fixed Barcode Scanner Module 1D 2D QR Bar

$35.50

≥1 Others
$30.00

≥50 Others
$26.50

≥200 Others

Options:

WGL-300-USB

Get Latest Price

Basic Info

Model No.	WGL-300-USB
Brand Name	winson
Certification	Ce
product status	Stock
Types of	Barcode Scanner
Scanning element type	Ccd, Cmos
Color point	32 Bit
Interface Type	Usb
place of origin	China
Warranty period (years)	1-Year
After-sales service	Call Center And On-Line Technical Support
Private Mold	Yes
Products Status	Stock
Type	fixed mount code scanner
Scan Element Type	Laser
Colour Depth	32 Bit
Interface Type	usb, SCSI, IEEE 1394, COM, PS/2
Max Paper Size	N/A
Optical Resolution	5mil
Scan Speed	100±20(scans/second)
Brand Name	Winson
Place Of Origin	Guangdong, China
Warranty(Year)	1-Year
After-sales Service	Call Center And On-Line Technical Support
Software development kit (SDK)	NO
Color	Black
Product Type	1D fixed mount barcode scanner
Interface	USB HID KEYBOARD/USB VCP/RS-232
Min X Dimension	DC 5V±10%
Current Consumption	Max:120mA
Light Source	650nm Visible Laser Diode
Voltage requirement	-20°to 65°C / -4°to 149°F
Min. PCS value	<25%UPC/EAN 13(13mil)
Shock drop test	1.2m drop onto concrete surface
Environmental	RoHS

Product description

Barcode Engine Application fields: parcel locker,supermarket locker, ticket machine, self-service vending machine, intelligent express cabinet, kiosk,locker, access control machine,self-service store, check-in machine, bank counter machine, factory assembly line,logistics, hospital,etc.

Barcode Scanner 360 Small size,easily to integrate into any device, especially for limit space application.

2d Scanner Barcode Auto-sensing scanning saves power and time -- when the product barcode passes through the scanning window, the module wakes up to read the barcode instantly.

Oem Scan Module 30M longer receiving distance

Embedded Scanner Supporting the RS232,USB,TTL,Micro USB interface.

Product Description

Specification

Interface	RS-232/USB HID KEYBOARD/USB VCP
Voltage requirement	DC5V±10%
Current consumption	Max :250mA
Photo sensor	CMOS array sensor
SENSOR RESOLUTION	1280x800 pixels
light source	White LED x1
Aim light source	red LED bar
Decode angle	Rotation angle：±70°；Skew angle：±70°；Tilt angle：±180°
Field of View	Level：53°,vertical：33°
