Basic Info
| Model No. | JFT-10B-1040C5-S9M |
|---|---|
| Brand Name | Yuheng |
| place of origin | China |
| Application | Machine tools, lathes, milling machines, grinders, machining centers, imaging equipment, other automation production equipment |
| Feature | anti-pollution, strong anti-interference, high resolution, high precision, power-off memory, high rigidity, reliable sealing |
| Connection type | Spring Plate |
| Output pattern | BISS |
Product description
In the process of installing the encoder, it is necessary to ensure that the rotor of the motor is different, otherwise the relative position of the rotor will be lost. If the relative position is lost, the old motor needs to use an oscilloscope to adjust the installation position of the encoder.

| Application |
|
Machine tools, lathes, milling machines, grinders, machining centers, imaging equipment, other automation production equipment |
| Feature |
|
anti-pollution, strong anti-interference, high resolution, high precision, power-off memory, high rigidity, reliable sealing |
| Model | [unit] | JFT-10B-1040C5-S9M |
| Mechanical parameter |
|
|
| Dimension | [mm] | 37*83.5 |
|
Shaft type |
|
180 |
|
Shaft size /aperture |
φ[mm] | 40.96 |
|
Max. rotate speed |
[r/min] | 5 |
|
Max. shaft load Axial / Radial |
[N] | 1040 |
|
Operating temperature |
[℃] | 0~+50 |
|
Protection level |
|
IP53 |
|
Connection type |
|
Spring Plate |
|
resolution |
[P/r] | 0.01 |
|
Electrical parameter |
|
|
|
Output pattern |
|
BISS |
|
Supply voltage |
DC[V] | 5 |
| Response frequency / Response rate | [KHz] | 10 |
|
Optional |
|
|
