Magnetic stripe card reader writer encoder

Options:

Max. rotate speed :［r/min］ 6000
Max. shaft load Axial / Radial? :［N］ 50/50
Operating temperature :［℃］ -20～+85
Protection level : IP65
resolution :［P/r］ 1200
Response frequency / Response rate: ［KHz］ 300

Get Latest Price

You might also like

Encoder motor position sensor

1 Pack/Packs (MOQ)

Through shaft of encoder

$53.00

1 Pack/Packs (MOQ)

Digital electronics encoder sensor

1 Pack/Packs (MOQ)

Incremental linear encoder encoder

1 Pack/Packs (MOQ)

Incremental shaft encoder encoder

1 Pack/Packs (MOQ)

Linear incremental encoder encoder

1 Pack/Packs (MOQ)

Hengstler micro encoder encoder

1 Pack/Packs (MOQ)

Smallest rotary encoder encoder

1 Pack/Packs (MOQ)

Small absolute rotary encoder

1 Pack/Packs (MOQ)

Encoder wheel sensor encoder

1 Pack/Packs (MOQ)

Basic Info

Model No.	B-ZXF-L-120BM-C8~26A
Brand Name	Yuheng
Application	CNC machine tools、automation、metallurgical industry
Feature	high protection level，economical
Model	［unit］ B-ZXF-L-120BM-C8～26A
Dimension	［mm］ Ф66*89
Shaft type	Solid shaft
Shaft size /aperture	φ［mm］ 15
Connection type	Coupling
Output pattern	?(7272B) Line driver
Supply voltage	DC［V］ 8～26

Product description

Automatic encoder is an unsupervised neural network model. It can learn the hidden features of input data, which is called coding. At the same time, it can reconstruct the original input data with the new features, which is called decoding.

B Zxf L 1

Application		CNC machine tools、automation、metallurgical industry
Feature		high protection level，economical
Model	［unit］	B-ZXF-L-120BM-C8～26A
Mechanical parameter
Dimension	［mm］	Ф66*89
Shaft type		Solid shaft
Shaft size /aperture	φ［mm］	15
Max. rotate speed	［r/min］	6000
Max. shaft load Axial / Radial	［N］	50/50
Operating temperature	［℃］	-20～+85
Protection level		IP65
Connection type		Coupling
resolution	［P/r］	1200
Electrical parameter
Output pattern		(7272B) Line driver
Supply voltage	DC［V］	8～26
Response frequency / Response rate	［KHz］	300
Optional
