Remove the encoder, turn the encoder by hand under the condition of continuous power supply, and observe the data displayed on the screen to see if there is any change, such as the data does not change.If there is any change, it proves that the encoder is good.

Application		Elevator、Servo motor
Feature		Sine-cosine、stable and reliable performance
Model	［unit］	ZND-1B-204.8BM/1
Mechanical parameter
Dimension	［mm］	φ65*57.5
Shaft type		Outer cone
Shaft size /aperture	φ［mm］	10
Max. rotate speed	［r/min］	500
Max. shaft load Axial / Radial	［N］	19.6/9.8
Operating temperature	［℃］	-40～+100
Protection level		IP50
Connection type		Spring Plate
resolution	［P/r］	2048
Electrical parameter
Output pattern		Sine-cosine
Supply voltage	DC［V］	5
Response frequency / Response rate	［KHz］	17.06
Optional
